SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
1 / 5
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO
SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO

SLS 3540 PRO Industrial Large-Format Selective Laser Sintering 3D Printer High-Temp Precision for End-Use Parts & Batch PRO

Customization: Available
After-sales Service: 1 Year
Warranty: 1 Year
Send Inquiry

Product Description

Basic Information

Model NO.
SLS 3540 Pro
File Format
STL
Connection
USB
Precision
0.3mm
Thickness
0.1-0.3mm
Printer Material
PA12
Forming Technology
SLS
Operating System
64 Bits Window 10
Transport Package
Carton
Specification
1350*950*1900MM
Origin
China
HS Code
8485200000
Production Capacity
20 Sets/Month

Product Specifications

Product ModelSLS3540 PRO
Printing Size350*350*430mm
Operating SoftwareProfessional Proprietary Software
Laser TypeFiber Laser, 1*300W
Layer Thickness0.1-0.3mm
Max Cabin Temperature190ºC
SupportsNo Need Support
Scanning Speed8-15m/s
Machine Size1650*980*1850mm
ScannerHigh-precision Digital Galvo System
Net Weight750KG
Inert Gas ProtectionNitrogen
Power Supply220V/50HZ
Max Volume Rate3000cm3/h
Compatible MaterialsPA11, PA12, TPU, Nylon with GF
Control FunctionsManual/Auto control, real-time modification, 3D visualization, diagnostics.
SLS 3540 PRO Detail 1 SLS 3540 PRO Detail 2 SLS 3540 PRO Detail 3 SLS 3540 PRO Detail 4 SLS 3540 PRO Detail 5 SLS 3540 PRO Detail 6

Frequently Asked Questions

What is the build volume of the SLS 3540 Pro?
The SLS 3540 Pro offers a generous printing size of 350*350*430mm, suitable for large-scale parts or batch production.
Does this 3D printer require support structures?
No, as it uses Selective Laser Sintering (SLS) technology, the unsintered powder acts as a natural support for the parts during the printing process.
What materials can be used with this machine?
The machine is compatible with a wide range of industrial materials including PA11, PA12, TPU, and Nylon reinforced with Glass Fiber (GF).
What are the environmental requirements for operation?
The recommended operating temperature is between 18-30ºC, and the system uses Nitrogen as an inert gas for protection.
What is the scanning speed and precision?
The printer features a high-precision digital Galvo system with scanning speeds ranging from 8-15m/s and a precision of 0.3mm.
What file formats does the software support?
The system primarily supports the industry-standard STL data format for 3D modeling and printing.
